Describe
Traction batteries are used as power sources for electric vehicles and material handling equipment, mainly including locomotives, electric forklifts, automatic navigation traction power supplies, golf
Share:
Traction batteries are used as power sources for electric vehicles and material handling equipment, mainly including locomotives, electric forklifts, automatic navigation traction power supplies, golf carts, etc. Their characteristic is to provide large current for a long period of time. The AGM separator produced by our company for traction batteries has small pore size, excellent rebound ability, low impurity content, strong mechanical strength, and excellent antioxidant capacity. These characteristics prevent active materials from peeling off the plates, reduce self-discharge, and prevent damage to the separator caused by handling, operation, assembly, and friction.
Index | |||||
---|---|---|---|---|---|
Thickness tolerance(mm) | ±5% | Basic weight(g/㎡mm) | 160±5%(20Kpa) | Strength(KN/m) | ≥0.42d |
Max pore diameter(μm) | ≤22 | Acid wicking g/g | ≥5.5(50Kpa) | Resistance(Ωd㎡/mm) | ≤0.0003 |
Resilience(%) | ≥94 | Porosity(%) | ≥92 | Climb acid height | ≥80(mm/5min) |
Water content(%) | ≤0.5 | Acid loss weight(%) | ≤3.0 | Climb acid height | ≥680(mm/24h) |
Iron(%) | ≤0.003 | Chlorine(%) | ≤0.003 | Loss ignition(%) | 3-6.5 |
