AGM Separator For Traction Battery

AGM Separator For Traction Battery

Describe

Traction batteries are used as power sources for electric vehicles and material handling equipment, mainly including locomotives, electric forklifts, automatic navigation traction power supplies, golf

Share:

Product Details



Traction batteries are used as power sources for electric vehicles and material handling equipment, mainly including locomotives, electric forklifts, automatic navigation traction power supplies, golf carts, etc. Their characteristic is to provide large current for a long period of time. The AGM separator produced by our company for traction batteries has small pore size, excellent rebound ability, low impurity content, strong mechanical strength, and excellent antioxidant capacity. These characteristics prevent active materials from peeling off the plates, reduce self-discharge, and prevent damage to the separator caused by handling, operation, assembly, and friction.



Index
Thickness tolerance(mm)±5%Basic weight(g/㎡mm)160±5%(20Kpa)Strength(KN/m)≥0.42d
Max pore diameter(μm)≤22Acid wicking g/g≥5.5(50Kpa)Resistance(Ωd㎡/mm)≤0.0003
Resilience(%)≥94
Porosity(%)≥92Climb acid height≥80(mm/5min)
Water content(%)≤0.5Acid loss weight(%)≤3.0Climb acid height≥680(mm/24h)
Iron(%)≤0.003Chlorine(%)≤0.003Loss ignition(%)3-6.5
